PORTABLE GARAGES

1 5/8″ Galvanized Gable-Style Framework

Available 12′ wide by 18′, 24′ or 30′ long!

12′ WIDE PORTABLE GARAGES

Versatile Storage Solutions for Smaller Equipment and Spaces

Our 12′ wide portable garages or carports are easy to set-up and take down. Unlike permanently constructed wood or steel buildings, they are cost-efficient and let natural light inside. These portable structures make great car/truck garages, carports, greenhouses, sheds, work shops, storage buildings as well as outfitters tents (using treated FR canvas).

Many Sizes
Available

Available 12′ wide by
12′, 18′, 24′ or 30′ long!

Six Colours to
Choose From

White, Translucent (Clear), Red, Silver, Blue or Green

Galvanized
Framework

1 5/8” (14 Gauge, 0.79 Wall Thickness) Galvanized Framework

Canadian
Materials Only

High-Quality Materials Sourced from Within Canada

Customization Options

Frame and Cover Can Be Customized to Meet Your Needs!

General Specifications

  • 12′ wide by 9′ peak height (7′ wall height) by 12′, 18′, 24′ or 30′ long. The length can be increased in 6′ increments.

  • 9’ wide x 7’ high industrial strength zippered roll-up door with crank

  • Doorwalls are available on one or both ends

  • 12” sod cloth for uneven grounds

  • 12” chuck wagon with 1” high strength poly webbing inside

Framework & Structural

  • 1 5/8” (14 gauge, 0.79 wall thickness) galvanized framework

  • 1 3/8” (14 gauge, 0.79 wall thickness) galvanized steel pipe for pipe pocket

  • Purlins are located in between every main frame for added wind and snow load strength

  • Anchors included, as well as ratchets and pipes to tension the cover

  • Five-year limited warranty on all structural parts

Portable Garage Dimensions

(click each picture for a bigger view)

Building Cover Material Options

NovaShield Logo Blue

Standard

400 Series
  • 12 oz Woven HDPE Scrim
  • 15-Year Limited Warranty
  • High Strength-to-Weight Ratio
  • Low Temperature Crack: -60°C (ASTM D2136)
  • >90% Strength Retention after 2000 hrs Exposure @ 0.77 W/m²/nm
  • Available in Clear, White, Red, Blue, Green, Silver

Standard + FR

400 Series FR
  • 12 oz Woven HDPE Scrim with FR Coating
  • 15-Year Limited Warranty
  • High Strength-to-Weight Ratio
  • Low Temperature Crack: -60°C (ASTM D2136)
  • >90% Strength Retention after 2000 hrs Exposure @ 0.77 W/m²/nm
  • Available in Clear, White, Red, Blue, Green, Silver

ELITE

ELITE Series
  • 13.8 oz Woven FR-UV HDPE Tapes with Engineered PE FR Film/Coating
  • 20-Year Limited Warranty
  • High Resistance to Crack Formation
  • High Level of Abrasion Resistance
  • Low Temperature Crack: -65°C (ASTM D2136)
  • >90% Strength Retention after 2000 hrs Exposure @ 0.77 W/m²/nm
  • Available in White Only

12 oz. Material Colour Options

All colours (except translucent) are white on the inside. Actual material colour may be different than displayed.

NovaShield 400 Series White

White

NovaShield 400 Series Translucent

Translucent

NovaShield 400 Series Red

Red

NovaShield 400 Series Green

Green

NovaShield 400 Series Blue

Blue

NovaShield 400 Series Silver

Silver

Different Building Applications

Greenhouse

Our 12′ wide portable garages also make great greenhouses!

The diffused translucent material is tougher than any plastic film and creates a very natural soft day light. Greenhouse packages come with a 8″ end vent to help with condensation.

Popular sizes are 12′ wide x 12′ or 18′ long.

Greenhouse Material 12oz Clear

Greenhouse Projects Coming Soon!

Outfitters Tent

If you’re thinking about setting up in the woods seasonally or all year round, we have a custom canvas option available.

We have a variety of FR canvases in different weights and different treatments available. Outfitters tents come with a 6″ stove ring sewn to the wall or roof.

Popular sizes are 12′ wide x 18′ or 24′ long.

Outiftters Tent Projects Coming Soon!

Parts Available

We have an extensive list of replacement parts for all of our buildings. We can also cut, bend and swedge galvanized pipe for you.

Replacement Covers

Our fabrication team can build replacement covers for any shape, make and size of building!

Frame Only Option

Interested in the frame only? No Problem! Our structures are available without the fabric cover as well.

Recent Projects

  • 12' Wide Portable Garage by 24' long, with Rolled-Up Door

Portable Garage Set-Up to View!

Fully Set-Up Portable Garage Outside Come Visit Our Show Room! Portable Garage Set-Up to View! We have a fully set-up 12' wide by 24' [...]

Looking for Something Bigger?

Our 15′ wide Boat & RV Shelters might just be what you’re looking for!

15' Wide Boat & RV Shelter Front

We Can’t Wait to Get You Started!

If you need more information don’t hesitate to ask us right away. Our customer service team will gladly assist you through any question or concerns.
